(4) Dual-shaft cylinder:
Two-axis cylinder is the two single-rod thin cylinder in parallel, the characteristics of the two-axis cylinder:


1, Embedded body installation fixed form, save installation space;
2, With a certain guidance, bending and torsion resistance, can withstand a certain side load;
3, The body front end anti-collision pad can adjust the cylinder stroke, and alleviate the impact, than the single-shaft cylinder output is larger.


(5) Guide rod cylinder:
Guide rod cylinder is divided into linear bearing type and copper jacket type, linear bearing type is suitable for pushing action, suitable for low friction sports occasions, copper jacket type is suitable for radial load, high load occasions.
Guide rod cylinder features: compact structure, can effectively save installation space, its own guiding function, can withstand a certain horizontal load, a variety of installation methods. Can be used for blocking, feeding, pushing, stamping, clamping and other occasions.


(6) Slide cylinder:
The cylinder of the slide table is guided by the cross ball guide rail, which has little friction and can achieve smooth movement without loosening.
Characteristics of slide cylinder:

1, Compact structure, save installation space;
2, High guidance accuracy, anti-torque, strong load capacity;
3, The price is relatively expensive.
